Poultry Cages & Battery Systems: Layer, Broiler, Brooder & Breeder Cages
Surya Poultry Division manufactures the full range of poultry cages and battery systems for layer, broiler, pullet, brooder and breeder birds. We have been building poultry equipment in Hisar, Haryana since 1996 and hold 4 patents, supplying farms and dealers across North India and beyond.
Most Indian layer farms still run on open-house A-type (California) cages, where the boxes step out in a pyramid so droppings fall clear and natural ventilation does the cooling. We make 3-tier A-type cages in 90, 96 and 120 bird configurations and 4-tier units up to 160 birds. For larger environment-controlled houses of 5,000-plus birds, our H-type automatic layer cage systems stack vertically (4 to 8 tiers) with a manure belt on every tier. All cages use hot-dip galvanized (HDG) wire for long service life in humid sheds.
- Layer cages: per-bird A/H-type, single replaceable boxes, and compact 30-bird 2-tier GI units for small farms.
- Broiler cages: battery cage boxes (8 to 12 birds) and per-sq-ft caged grow-out systems.
- Brooder & pullet cages: steel multi-tier baby-chick cages and grower cages for chicks 8 to 16 weeks.
- Breeder & colony cages: separate male/female breeder boxes and welfare-oriented enriched colony cages.
We also supply cage accessories such as nipple drinking lines, feeding troughs, travelling feed trolleys, egg roll-out trays and manure trays, plus full semi-automatic and fully automatic cage houses. Tell us your bird count, shed size and house type on WhatsApp and our team will recommend the right cage and share a quote.
Poultry Cages & Battery Systems from Surya
Layer Battery Cage (Per-Bird Basis)
A-type or H-type; 5 to 10 birds per box; hot-dip galvanized wire; bare cage steel only
Enquire on WhatsAppLayer Battery Cage Box (Single Unit)
3 to 8 birds per box; HDG wire; single replaceable box
Enquire on WhatsAppA-Type (California) Layer Cage, 3-Tier
90, 96 or 120 birds; pyramid stack; for open naturally ventilated sheds
Enquire on WhatsAppA-Type (California) Layer Cage, 4-Tier
128 or 160 birds; higher density pyramid; HDG steel
Enquire on WhatsAppH-Type Automatic Layer Cage System, 4 to 8 Tier
4, 5, 6 or 8 tier; vertical stack with manure belt per tier; HDG; for EC houses of 5,000+ birds
Enquire on WhatsAppGI Layer Cage, 30-Bird 2-Tier
30 birds; compact 2-tier; small-farm unit
Enquire on WhatsAppBroiler Battery Cage Box
grow-out; 8 to 12 birds per box; hot-dip galvanized
Enquire on WhatsAppBroiler Cage System (Per Sq Ft)
full caged broiler rearing; multi-tier; mechanized harvest option
Enquire on WhatsAppPullet / Grower Cage
for chicks 8 to 16 weeks; GI wire; multi-tier
Enquire on WhatsAppBrooder / Baby Chick Cage (Steel Multi-Tier)
day-old to 7-8 weeks; 3 to 4 tier; A or H type; up to 160 chicks per unit
Enquire on WhatsAppPlastic Brooder Cage (5-Bird)
5 birds; moulded plastic; small batch
Enquire on WhatsAppBreeder Cage (Layer Breeder)
separate male and female boxes; 2 to 6 tier; designed to improve fertility and hatching-egg output
Enquire on WhatsAppColony / Enriched Colony Cage
perching and nesting area; stainless or GI; group housing; welfare-oriented
Enquire on WhatsAppCage Frame / Structure (Bare)
GI or MS uprights, cross-members and legs; sized to tier count and row length
Enquire on WhatsAppCage Nipple Drinking Line (In-Cage)
nipple plus PVC or SS pipe plus pressure regulator; one line per cage row
Enquire on WhatsAppCage Feeding Channel / Trough (Linear)
GI or PVC trough strip along the cage row; sold per running foot
Enquire on WhatsAppCage Feed Trolley / Travelling Feeder
hopper trolley running on cage rails; fills all troughs in a pass; manual or motorized
Enquire on WhatsAppEgg Collection Tray / Roll-Out Channel
sloped egg-roll tray per cage tier; feeds manual pick-up or auto belt
Enquire on WhatsAppManure / Dropping Tray
GI or plastic tray fitted under each tier
Enquire on WhatsAppDropping Board (A-Type)
sloped GI board guiding droppings between A-type tiers to the floor
Enquire on WhatsAppCage Assembly Hardware (J-Clips, Clips, Wheels)
J-clip and clip kits, clip pliers, repair wire, casters and levelling feet
Enquire on WhatsAppAutomatic Egg Collection System (Cage House)
belt collection across all rows; per full house; multiple capacity options
Enquire on WhatsAppAutomatic Manure Removal (Belt or Scraper)
manure belt per tier or floor scraper line; per house
Enquire on WhatsAppManure Drying / Composting Tunnel
in-house belt drying that reduces manure moisture and odour; per house
Enquire on WhatsAppCage-Free Aviary / Multi-Tier Floor System
perch, nest box and slat aviary layout for cage-free egg production; per house
Enquire on WhatsAppSemi-Automatic Layer Battery System
cages plus feed trolley plus manure belt; per house
Enquire on WhatsAppFully Automatic Layer Cage House
auto feed, auto drink, auto egg collection, auto manure; environment-controlled house
Enquire on WhatsAppHow to choose the right poultry cage
The right cage depends on your bird type, flock size and shed.
- Open shed, up to a few thousand layers: A-type (California) cages are the practical choice. They are cheaper to install, easy to manage by hand and need no power for ventilation. Pick 3-tier (90/96/120 birds) for easier access or 4-tier (128/160 birds) when you want more birds in the same shed length.
- EC house, 5,000+ layers: H-type systems give the highest bird density per square foot and pair with manure belts, auto feeding and automatic egg collection to cut labour.
- Broilers: caged rearing keeps litter problems down and birds cleaner. Choose battery boxes for smaller batches or per-sq-ft systems for full sheds.
- Chicks and pullets: brooder cages (day-old to 7-8 weeks) and grower cages protect young birds and make brooding management easier.
Cage steel is usually quoted bare (cage only), with drinking lines, feeders, trays and automation added per your requirement. Share your plan on WhatsApp and we will help you size it correctly.
Common questions
What is the difference between A-type and H-type layer cages?
A-type (California) cages stack in a stepped pyramid so droppings fall to the floor and birds get natural airflow, which suits open, naturally ventilated sheds and small to mid-size flocks. H-type cages stack vertically with a manure belt under each tier, giving much higher bird density per square foot, and are built for environment-controlled houses of 5,000-plus birds with automation. Tell us your shed type and bird count on WhatsApp and we will advise.
How many birds fit in one layer cage box?
Our layer battery cage boxes typically hold 3 to 8 birds per box on a per-bird basis. A-type 3-tier units come in 90, 96 and 120 bird configurations and 4-tier units in 128 or 160 birds. We can quote per bird, per box or per complete row to match your shed.
Do you make cages for broilers and baby chicks too?
Yes. We make broiler battery cage boxes (8 to 12 birds), full per-sq-ft caged broiler systems, steel multi-tier brooder cages for day-old chicks up to 7-8 weeks, plastic 5-bird brooder cages and pullet/grower cages for chicks 8 to 16 weeks. Message us on WhatsApp with your batch size.
Are your cages galvanized, and how long do they last?
Our cages use hot-dip galvanized (HDG) wire, which resists rust far better than plain or electro-galvanized wire in humid, ammonia-heavy poultry sheds. With normal cleaning, HDG cages give many years of service, which is why most commercial layer farms specify them. Frames are available in GI or MS.
How do I get a price for layer or broiler cages?
Prices depend on cage type, tier count, bird capacity, steel specification and the accessories or automation you need, so we quote each enquiry individually. Send your bird count, shed dimensions and whether the house is open or environment-controlled on WhatsApp and our Hisar team will share a quote.
Order direct from the maker
Surya Group of Industries has manufactured poultry equipment in Hisar, Haryana since 1996. Message us with your bird count and shed size for a quote, freight, and delivery anywhere in India.
